Low Voltage Fuse Holder Fuse Base for Fuse

Name: Low Voltage Fuse Holder Fuse Base for Fuse
Brand: all-electronics-online.com
SKU: 753907415
Availability: InStock
Rating: 4.3 (84 reviews)

Price:	US $ 0.3-4/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	RT18-32
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Certificate:	CE
Breaking Capacity:	High
Type:	Current Fuse
Usaga:	Low Voltage

Product Description

Specification

Type	Assorted Fuse	Rated Voltage (V)	Rated Current (A)	Dimension
Type	Assorted Fuse	Rated Voltage (V)	Rated Current (A)	A	B	C	D	E
RT18-32 1P	10 x 38	380	32	82	78	35	63	18
RT18-32 2P			32	82	78	35	63	36
RT18-32 3P			32	82	78	35	63	54
RT18-63 1P	14 x 51		63	106	103	35	80	26
RT18-63 2P			63	106	103	35	80	52
RT18-63 3P			63	106	103	35	80	78
RT18-32X 1P	10 x 38		32	82	78	35	63	18
RT18-32X 2P			32	82	78	35	63	36
RT18-32X 3P			32	82	78	35	63	54
RT18-63X 1P	14 x 51		63	106	103	35	80	26
RT18-63X 2P			63	106	103	35	80	52
RT18-63X 3P			63	106	103	35	80	78

Model	Matched Fuse Link	Rated Voltage (V)	Rated Current(A)	Dimension
Model	Matched Fuse Link	Rated Voltage (V)	Rated Current(A)	A	B	C	D	E
RT18L-63 1P	14 x 51	690	63	115	108	78	100	27
RT18L-63 2P				115	108	78	100	54
RT18L-63 3P				115	108	78	100	81
RT18L-63 4P				115	108	78	100	108
RT18L-125 1P	22 x 58		125	134	126	78	104	36
RT18L-125 2P				134	126	78	104	72
RT18L-125 3P				134	126	78	104	108
RT18L-125 4P				134	126	78	104	144
