MCB Dz47le-63 2p Leakage Mini Circuit Breaker
| Price: |
US $ 1.72-1.88/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
200/Piece |
| Pay Type: |
L/C,T/T,Western Union,Paypal |
| Prod Model: |
DZ47LE-63 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model Number: |
MCB Dz47le-63 |
| Rated Voltage: |
:220/380V |
| Rated Current: |
1~60A |
| Leakage Current: |
30/100mA |
| Poles: |
1/2/3/4p |
| Place Of Origin: |
Zhejiang, China |
| Breaking Capacity: |
Low Voltage Circuit Breakers |
| Operation: |
Manual Type |
| Speed: |
Normal Type Circuit Breaker |
| Arc-extinguishing Medium: |
Air |
| Installation: |
Fixed |
| Structure: |
MCCB |
| Poles Number: |
3 |
| Certification: |
CCC |
Product Description
DZ47LE earth leakage circuit breaker is used for protecting against electrical leakage in the circuit of 50Hz or 60Hz, rated voltage single-phase 240V, three phases 415V, rated current up to 60A. If the current exceeds the fixed value, the ELCB can cut off the power within the time of 0.1s automatically to protect the personal residual current. With this function, the ELCB can protect the unfrequent switch-over of the circuit under normal conditions. It conformsto IEC1009.1 and GB16917.1.
Specifications
MCB DZ47LE-63 2P LEAKAGE MINI CIRCUIT BREAKER
MCB DZ47LE-63 2P LEAKAGE MINI CIRCUIT BREAKER
1.Rated voltage:220/380V
2.Rated current:1~60A
3.Leakage current:30/100MA
4.Poles:1/2/3/4P
5.Standard:IEC60898/IEC60755
Application:
MCB DZ47LE/63 earth leakage circuit breaker is used for the protection against electrical leakage in the circuit of 50Hz or 60Hz, rated voltage single-phase 240V, 3 phase 415V, rated current up to 60A. when somebody gets an electric shock or the residual current od the circuit exceeds the fixed value, the ELCB can cut off the power within the time of 0.1s automatically protecting the personal safety and preventing the equipment from the fault resulted from the residual current. With this function, the ELCB can protect the circuit against overload and short circuit or can be used for the unfrequent switch over of the circuit under normal conditions. It conforms to IEC 60898&IEC60755
|
MCB SPECIFICATION: |
Rated
Voltage(V) |
Pole No |
Rated current
(A) |
Leakage
action
current(mA) |
Leakage
dead
current(mA) |
Leakage
action time(s) |
220V |
1P |
1~10 |
30 |
15 |
<0.1 |
380V |
2,3,4P |
15~32 |
100 |
50 |
40~60 |
a.TH35-7.5 rail is used for the product installation
b. Outline and installation dimensions(see the figure and the table)| Type | Dimensions | | A | B | C | D | E | | DZ47L-60/1N | 46 | 70 | 40 | 45 | 94 | | DZ47L-60/2 | 64 | 70 | 40 | 45 | 94 | | DZ47L-60/3 | 91 | 70 | 40 | 45 | 94 | | DZ47L-60/3N | 100 | 70 | 40 | 45 | 94 | | DZ47L-60/4 | 118 | 70 | 40 | 45 | 94 |
|
MCB MIN TECHNICAL DATA: |
Single-pole
double line |
Double-pole
double line |
Triple-pole
triple line |
Triple-pole
four line |
Four-pole
four line |
DZ47L
C45LS
1/2 |
DZ47L
C45LS
2/2 |
DZ47L
C45LS
3/3 |
DZ47L
C45LS
3/4 |
DZ47L
C45LS
4/4 |
|
|
Yueqing Heng Nuo Imp. & Exp. Co., Ltd. is the export department for TENGEN GROUP Co., Ltd, it is one leading manufacturer and exporter in the fields of electrical apparatus, wiring accessories, hardware, fire alarm system, tools and so on, our company located in Liushi town of Wenzhou city where is the largest production centre in China for electrical products.
From 1983 to now, our company has cooperated with more than 80 factories, and produces over 20 kinds, thousands of models of high quality electric products yearly. Mainly including:
1. Electrical apparatus: Circuit breaker, AC contactor, Relay, fuse, timer, counter, distribution box, meter socket, current transformer, meter, pushbutton switch, LED pilot lamp, limit switch, pedal switch, float switch, industrial plug & socket, Stabilizer and so on.
2. Wiring accessories: Cable tie, cable clip, cable puller, cable marker, cable lugs, cable glands, terminal blocks, wiring ducts, insulated terminals, MCB insulated busbar, dinrail and so on.
3. Hardware: Flexible conduit & connector, EMT fittings, Metal switch boxes and so on.
4. Tools: Hand crimping tools, cable cutter, hydraulic crimping tool, tester, screwdriver and so on
5. Fire alarm and warning system: Fire alarm bell, electric bell, smoke detector, motor siren, buzzer, warning light and so on
Internationalization standard quality guarantee system:
The product quality of Tengen Group has been strictly controlled in each working procedure,
Many kinds of internationalization standard quality guaranteed system can be highly effective
Under company's strict monitoring. Fellowtrader commended, customer's approval can sufficiently
Make sure of our product quality.
"Tengen" was evaluated as " Chinese famous trademark", Tengen Group has obtained American
FMRC Corporation ISO9001 quality system authentication, ISO14001 environment management
System authentication, CCC authentication, European Union CE safe Authentication, American UL
Authentication and Dutch KEMA authentication and so on, at the same time, it has had the first
Side laboratory -- low voltage electric appliance test center which is the first connected with
International in China.
We promise to offer you superior products, favorable price, and timely delivery. If you are interested in cooperating with us, please feel free to contact with us in your earliest convenience time.
