PM Versions Fiber Optical ST APC Polish Types Online Fixed Attenuator

Name: PM Versions Fiber Optical ST APC Polish Types Online Fixed Attenuator
Brand: all-electronics-online.com
SKU: 818208625
Availability: InStock
Rating: 4.8 (148 reviews)

Price:	US $ 3-5/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	PN-016
Back Reflection (Typical):	55 dB
Cable Assemblies:	900 um
Buildout Attenuators:	SM: Ceramic mm: Phosphorus Bronze
Polish Type:	APC
Use In:	DWDM
Application:	Communication
Type:	Single-mode Fiber
Connection Structure:	ST
Certification:	ISO9001
Sheath Material:	Metal

Product Description

PM Versions Fiber Optical ST APC Polish Types Online Fixed Attenuator

Fixed Attenuators from Timbercon offer defined control of optical signals in both integrated and add-on products. Depending on the project or need, fixed attenuators can limit, or attenuate, the amount of light passing through to the exact level your project or application requires. PUNO Fixed Attenuators are used in applications where a pre-determined amount of light loss is specified. Though its applications range widely, fixed attenuators are most commonly used for test and measurement, optical sensors, and telecommunications applications. Available in both inline and terminator/build-out styles, Timbercon Fixed Attenuators offer multiple options including SC, LC, ST, FC, and MU connector types and definable attenuation values from 1db to 20dB.

Features:

√ Single Mode, multimode, and PM versions;
√ Core off-set, air gap, and filtered attenuation methods;
√ Low insertion loss and back reflection;
√ Compact size;
√ Definable attenuation from 1db to 20dB;
√ PC, UPC, and APC polish types;
√ Available with FC, SC, ST, LC, and MU terminations.

Benefits:

√ Multiple fiber types for use in different systems and applications;
√ Different attenuation methods for increased attenuation level precision with different fiber types;
√ Compact size decreases physical space requirements;
√ Precise attenuation levels provide highly accurate performance;
√ Connector and polish options allow seamless integration into existing systems.

Applications:

√ DWDM applications;
√ Test & measurement;
√ Optical sensors;
√ Telecommunications applications.

Performance:

Insertion Loss (Typical)	SM	MM
FC, ST, SC, LC, MU	0.15 dB 0.30 dB	0.35 dB 0.30 dB
Back Reflection (Typical)	-55 dB	-35 dB
Mating Durability (500 Cycles)	0.20 dB	0.20 dB
Temperature Range	-40ºC to 85ºC	-40ºC to 85ºC

Construction:

Cable Assemblies	Buffer	Strength Member	Jacket
900um	900um	-	PVC
3mm Riser	900um	Kevlar	PVC
3mm Plenum	900um	Kevlar	PVDF
Length Tolerance (Cables)	<1m: +5cm / -0cm 1m - 10m: +10cm / -0cm >10m: +2% / -0%
Buildout Attenuators
SM: Ceramic MM: Phosphorus Bronze
