RO Series Spiral Fuse Link

Name: RO Series Spiral Fuse Link
Brand: all-electronics-online.com
SKU: 757267555
Availability: InStock
Rating: 4.7 (28 reviews)

Price:	US $ 0.1-0.22/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1000/Piece
Pay Type:	L/C,T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	RO, RS
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Current:	2-25A
Size:	Di, Dii, Diii, Div
Type:	Current Fuse
Breaking Capacity:	High
Usaga:	High Voltage

Product Description

Specification

Model		Size	Rated Current(A)	Dimension(mm)
GG	AR	Size	Rated Current(A)	A	C	D	L
RO 21	RS 21	DII	2,4,6	6	22	13	50
			8, 10	8	22	13	50
			13	8	22	15	50
			16	10	22	15	50
			20	12	22	15	50
			25	14	22	15	50
RO 22	RS 22	DIII	30, 35, 40	16	27	20	50
			50	18	27	20	50
			63	20	27	20	50
RO 23	RS 23	DIV	2, 4, 6	6	27	20	70
			8, 10	8	27	20	70
			16	10	27	20	70
			20	12	27	20	70
			25	14	27	20	70
			35	16	27	20	70
			50	18	27	20	70
			63	20	27	20	70
RO 24	RS 24	DI	2, 4, 6	6	12.5	11.3	50
			10	8	12.5	11.3	50
			16	10	12.5	11.3	50
			20, 25	12	12.5	11.3	50
