Prod Model: |
W16 |
Certification: |
UL TUV CQC |
Contact Material: |
Agsno2 Agni |
Installation Type: |
PCB |
UL Insulation Class: |
F |
Operate Time: |
Max.10ms |
Release Time: |
Max.5ms |
Weight: |
6g |
Product Description
Basic Info
Model NO.: W16
Contact Form: 1A = 1 OPEN 1B= CLOSE 1C= 1 Switch
Product protective: S=Sealed Nil= Soldered
Contact material: T=AgSnO2 Nil:= AgNi
Coil Power: Nil= Standard L = Sensitive
Load: Nil:Standard Load E=High Load (10A)
Insulation System:Nil:B grade F= F grade
Dimension: 20.5*10.5*15.5 MM
Weight: Approx 6g
Trademark: FANHAR
Origin: China
Product Description
1. 10A contact switching capability
2. Creepage distance and spacial distance are greater than 8mm.
3.UL insulation class : F grade.
Contact Data:
Contact Form | 1A 1B 1C |
Rated load | 10A 250VAC 5A 250VAC/30VDC |
Max Switching Voltage | 277VAC/30VDC |
Max Switching Current | 10A |
Max Switching Capacity | 2500VA/150W |
Min Allowing load | 5VDC 100mA |
Contact Resistance | 100mΩ (at 6VDC 1A) |
Insulation Resistance | 1000MΩ (at 500VDC) |
General Data:
Withstand Voltage Between open contacts | 1000VAC 1min |
Between coil and contacts | 4000VAC 1min |
Withstand impact voltage | Between coil and contacts 8kv(1.2X50us) |
Operate Time | Max.10ms |
Release Time | Max.5ms |
Mechanical life | 5,000,000 ops ON/OFF = 0.1s/0.1s |
Electrical life | 5A 250VAC/30VDC 50,000 ops ON/OFF=1s/9s 10A 250VAC 30,000 ops ON/OFF=1s/9s 3A 250VAC/30VDC 100,000 ops ON/OFF=1s/9s |
Impact Resistance Misoperation Durability | 100m/s² Approx10G 1000m/s² Approx100G |
Vibration Resistance Misoperation Durability | 10 - 55 Hz 1.5mm Double Amplitude 10 - 55 Hz 1.5mm Double Amplitude |
Temperature Range | -40ºC to +85ºC |
Humidity | 5% to 90% |
Installation type | PCB Mounting |
Certification | UL/C-UL:E475405 TUV:R50346373 CQC:CQC16002144114 |
Coil Data:
Standard:
Coil rated voltage | Operating voltage | Releasing Voltage | Coil rated Current (±10%) | Coil resistance(±10%) | Rated consumed power | Allowing voltage |
DC 3V | Below 75% rated voltage (initial) | above 5% rated voltage (initial) | 150mA | 20Ω | 450mW | 90-130 % Rated voltage |
DC 5V | 90mA | 55.5Ω |
DC 6V | 75mA | 80Ω |
DC 9V | 50mA | 180Ω |
DC 12V | 37.5mA | 320Ω |
DC 15V | 30mA | 500Ω |
DC 18V | 25mA | 720Ω |
DC 24V | 18.8mA | 1280Ω |
DC 48V | | | 10.4mA | 4608Ω | 500mW | 90-110 % Rated voltage |
Sensitive:
Coil rated voltage | Operating voltage | Releasing Voltage | Coil rated Current (±10%) | Coil resistance(±10%) | Rated consumed power | Allowing voltage |
DC 3V | Below 75% rated voltage (initial) | above 5% rated voltage (initial) | 66.7mA | 45Ω | 200mW | 90-130 % Rated voltage |
DC 5V | 40mA | 125Ω |
DC 6V | 33.3mA | 180Ω |
DC 9V | 22.2mA | 405Ω |
DC 12V | 16.7mA | 720Ω |
DC 15V | 13.3mA | 1128Ω |
DC 18V | 11.1mA | 1620Ω |
DC 24V | 8.3mA | 2880Ω |
