Immersion Gold Circuit Board Halogen Free PCB Taconic Tla-35 0.762mm
| Price: |
US $ 0.95/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
BIC-676-G6.76 |
| Aluminum Core: |
3W / Mk Dielectric Material |
| Minimum Trace And Space: |
11 Mil/11.5 Mil |
| Minimum / Maximum Holes: |
8.5mm |
| Final Foil External: |
1 Oz |
| Final Height Of PCB: |
1.6mm |
| Surface Finish: |
Electroless Nickel Over Immersion Gold (Enig) |
| Solder Mask Color: |
Black |
| Colour Of Component Legend: |
No Required |
| Via: |
No Via |
| Test: |
100% Electrical Test Prior Shipment |
| Type: |
Rigid Circuit Board |
| Flame Retardant Properties: |
V0 |
| Material: |
Aluminum |
| Dielectric: |
Aluminum 5052 |
Product Description
Company ProfileAn Experienced PCB Provider since 2003
Established in Shenzhen in 2003, Bicheng Enterprise Limited is an experienced PCB supplier.
We are widely-recognized and have a strong network in the PCB industry. As an ISO 9001-2008
-,ISO 14001-2004-, ISO/TS 16949:2009- and UL-compliant, we offer different types of PCB from
fiberglass, high frequency, metal core and ceramic. Our 16,000-square-meter factory can produce
30,000 square meters with 8,000 types of PCB per month.
Various PCBs are Available
Our extensive product line includes double-sided PCBs, multi-layer PCBs (up to 32 layers), FR-4
PCBs (Tg130 - Tg170), high frequency PCBs (RO4350B, RO4003C), aluminum PCBs (1W/MK,
2W/MK, 3W/MK), flexible PCBs and HDI PCB boards.
Having Multiple PCB Technology to Meet the Market Demands
Our plants use state-of-the-art equipment during our production and testing phase in order
to ensure quality and to meet the market demands. These include heavy copper testers,
impedance control testers, automatic target drill machines, PCB cleaning machines and
more.
Offering New Customer Promotion
For new customers, we offer SMT stencil foil, PCB panelization and prototype testing free of
charge.
Our other advantages include:- Our engineering design prevents problems from occurring during pre-production
- We can meet your PCB needs from prototype to mass volume production
- Eligible products rate of first production: >95%
- Delivery on time: >98%, door to door shipment service
- Customer complaint rate: <1%
Our advantages help you maximize your profit by saving time and cost. Contact us now.
