M5 3 Pin Male Straight Molded Cable Connector

Name: M5 3 Pin Male Straight Molded Cable Connector
Brand: all-electronics-online.com
SKU: 823744055
Availability: InStock
Rating: 4.6 (47 reviews)

Price:	Negotiable/Piece
Min Order:	10/Piece
Pay Type:	L/C,T/T,Western Union,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	MA03C1LSG3AB14
Standard:	IEC 61076-2-105
Connection Type:	Single Ended Cable
Key Coding:	a-Coding

Product Description

M5 3 pin male straight molded cable connector

1.Descriptions

The M5 connectors provide 3 and 4 position cable cordsets and panel-mounted receptacles. All connectors are either factory PUR/PVC overmolded or supplied with attached wire leads.
(1) PUR or PVC overmolded
(2) Threaded nut immune to vibration
(3) Degree of protection IP 67
(4) Available with 3 or 4 poles
(5) Cable length 1m, 2m, 3m (PUR) or upon customized specification

2.Material data

Contacts plating:Gold plated, thickness 3μ"

Insert/ Housing:TPU

Coupling nut/screw:Brass with nickel plated screw

Wire insulation:PVC

Overmold/ Shell:TPU

Connector contacts:Brass with gold plated

Number of Contacts	03 Pin	Sealing	O-ring
Insulation resistance	≥100 MΩ	Shielding	Non-Shielded
Contacts resistance	≤ 5 mΩ	Coding	A-code
Rated current	1 A	Orientation	Straight
Rated voltage	60 V	Termination	Soldering

3.Applications

(1) Miniature sensors
(2) Industrial camera
(3) Electrical bike
(4) Packaging, Labeling & Logistic
(5) Factory automation and fieldbus module

4.Product packing
(1) Our standard packing: Individual part with transparent PE bag with label;
(2) Carton size: 44.5*36.5*23.5(mm)
(3) OEM package available
(4) Delivery : 1~ 3 weeks

5.FAQ
(1) Q:Are you a manufacturer or trading company?
A:We are a connector factory.

(2) Q: What is the necessary information needed for quotation?
A:The series(M5,M8,M12,7/8"), coding, male or female, pin number, cable length etc.

(3) Q:What does Cableforce can provide for the product' certification?
A: IP67, CE and RoHS.

(4) Q:Can you provide samples?
A:Of course can be provided.

(5) Q:Sample lead time?
A:2-4 workdays

(6) Q: Volume order lead time?
A:3-10 workdays

(7) Q: How do you ship the finished product?
A:we can contact the shipping company or your shipping agent.The formal shipping way:DHL,FEDEX,UPS,TNT

Company Profile

Cableforce focuses on the industrial cable and connector's Research, Development, Sales and Manufacture. We located in Dongguan City, in the southern China, with 2100 premises and efficient modern machinery and equipments for tooling & prototyping, cable cutting, soldering, crimping, plastic injection molding, testing and manual assembly lines allow products to be manufactured in both large volume and small customized lots whilst maintaining a favorable cost and quality ratio.

Business

CABLEFORCE globally offers a wide variety of industrial connectors and cable connectivity solutions to meet either standard or harsh environment signal and power transmission application. Its wide range of metric circular connectors and cable assembly that fit almost any standard sensor or actuator application and includes features such as accurate IP ratings, a wide range of cable jackets, and multiple contacts pin configurations, and high quality rugged materials.

Products range

Circular connectors for industrial applications: M5/ M8/ M12/ M23/ 7/8" series;

Field-Bus cables: DeviceNet cable, Ethernet cable, Profibus cable, Profinet cable, CANopen;

NMEA 2000 cable and connectors: Backbone cable, Drop line cables, T connectors, Terminators;

I/O Link Connectors: USB 2.0/3.0, RJ-45, D-SUB connectors.
