Multilayer Rigid-Flexible PCB 4 Layer FPC 1.0mm Thick Board
| Price: |
US $ 1.35/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
BIC-1827-V25 |
| Inner Copper Thick: |
35 Um (1oz) |
| Outer Copper Foil: |
35 Um (1oz) |
| Board Thickness: |
1.0mm |
| Coverlay Colour: |
Yellow and Green |
| Color of Silkscreen: |
White |
| Peeling Test of Coverlay: |
No Peelable |
| Surface Finish: |
Immersion Gold |
| RoHS Required: |
Yes |
| Thickness of Coverlay: |
25 µm |
| Test: |
100% Electrical Test |
| Structure: |
Multilayer FPC |
| Material: |
Polyimide |
| Combination Mode: |
Adhesive Flexible Plate |
| Conductive Adhesive: |
Conductive Silver Paste |
| Application: |
Micro USB |
Product Description
Multilayer Rigid-Flexible PCB 4 Layer FPC 1.0mm thick board 416
Commodity Introduction
This is a type of Rigid-flexible PCB for the application of Micro USB. It's a 4 layer rigid-flex board at 1.0mm thick. The base laminate is from ITEQ, It's fabricated per IPC 6012 Class 2 using supplied
Gerber data.
Parameter & Data Sheet| Size of Flexible PCB | 20.61 X 50.17mm |
| Number of Layers | 4 |
| Board Type | Rigid flex PCB |
| Board Thickness | 1.0mm |
| Board Material | 1.0mm FR-4 / Polyimide 25µm |
| Board Material Supplier | ITEQ |
| Tg Value of Board Material | 60ºC |
| |
| PTH Cu thickness | ≥20 µm |
| Inner Iayer Cu thicknes | 35 µm |
| Surface Cu thickness | 35 µm |
| | |
| Coverlay Colour | Yellow coverlay / Green solder mask |
| Number of Coverlay | 2 |
| Thickness of Coverlay | 25 µm |
| Stiffener Material | no |
| Stiffener Thickness | N/A |
| | |
| Type of Silkscreen Ink | IJR-4000 MW300 |
| Supplier of Silkscreen | TAIYO |
| Color of Silkscreen | White |
| Number of Silkscreen | 1 |
| |
| Peeling test of Coverlay | No peelable |
| Legend Adhesion | 3M 90ºC No peeling after Min. 3 times test |
| |
| Surface Finish | Immersion Gold |
| Thickness of Nickle/Gold | Au: 0.03µm(Min.); Ni 2-4µm |
| RoHS Required | Yes |
| Famability | 94-V0 |
| |
| Thermal Shock Test | Pass, -25ºC±125ºC, 1000 cycles. |
| Thermal Stress | Pass, 300±5ºC,10 seconds, 3 cycles.
No delamination, no blistering. |
| Function | 100% Pass electrical test |
| Workmanship | Compliance with IPC-A-600H & IPC-6013C Class 2 |
Rigid-Flex Printed Circuit Boards
A rigid-flex PCB is a combination of rigid boards and flexible circuits, the latter creating flexible inter-connects between the rigid boards to which they are laminated by means of bond plies.
The flexible circuit is manufactured separately and bonded to the rigid boards, either symmetrically, i.e., in the middle of the rigid boards, or asymmetrically, i.e., to the outer side of the rigid boards to
be interconnected.Frequent Asked Questions
1). What courier do you use for shipment?
Our courier includes DHL, FedEx, TNT and EMS. As per your order weight and location, we'll choose the most economic method to send you your boards to help to save the freight cost.
2). How do you pack the PCBs?
PCBs are packed with Polyethylene air cushion film (vacuum plastic bags) per 20-25 pieces.
Pearl cotton (Polyethylene foamed sheet) are put inside carton box.
The hardness of carton box is KK grade (the highest hardness). Maximum gross weight for one
carton is less than 12 kgs.
3). How to Pay?
We accept bank wire transfer, PayPal. It's sorry, we currently do not accept credit card.
4). How to order PCBs?
1st step, sending your gerber files for quotation.
2st step, placing your order form to our market department and make the payment.
3rd step, Our CADCAM department is dealing with your gerber files, sending you EQ (if it has)
for final confirmation.
4th step, PCB is manufactured.
5th step, Shipment and send you tracking number.
5). How do you control the quality?
We believe engineering design prevents problems from occurring in preproduction. Our PCB and
Manufacturing process are certified by authorized organizations.100% tests are inclusive of
electrical test and AOI inspection, high voltage test, impedance control test, micro-section, solder-
ability test, thermal stress test, reliability test, insulation resistance test and ionic contamination test
etc.
