Non-Conductive Via Fill PCB Circuit Board 1.2mm Thick Circuits
| Price: |
US $ 1.01/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union |
Company Profile
Bicheng Enterprise Limited which was founded in 2003 is a leading PCB expert that specializes in
supplying high-tech PCB in high mixed, fast prototype, small to medium volume. We're capable of
supplying PCBs up to 32 layers inclusive of HDI circuit boards, flexible circuits, rigid-flex boards,
hybrids, halogen-free boards, metal-based PCB, high frequency PCB, heavy copper (up to 12
oz) PCB etc. which are in the applications of high-tech products.
The manufacturing facility is certified with ISO9001, ISO14001 & TS16949.Our products are widely
used in Telecom, Industrial Control, Networks, Healthcare, & Automotive Industries
High Frequency PCB
Flexible Printed Circuit
Metal Core PCB
PCB Board
Technology Information
RO4350B & RO4003C Data Sheets| Property | Typical Value | Direction | Units | Condition | Test
Method |
| | RO4003C | RO4350B | | | | |
Dielectric
Constant,
εr Process | 3.38±0.05 | 3.48±0.05 | Z | - | 10 GHz
/23ºC | IPC-TM
-650 2.5.5.5
Clampled
Stripline |
Dielectric
Constant,
εr Design | 3.55 | 3.66 | Z | - | 8 to 40
GHz | Differntial
Phase
Length
Method |
Dissipation
Factor Tan,
δ | 0.0027
0.0021 | 0.0037
0.0031 | Z | - | 10 GHz
/23ºC
2.5 GHz/
23ºC | IPC-TM
-650
2.5.5.5 |
Thermal
Coefficient
of εr | 40 | 50 | Z | ppm/ºC | minus
50ºC
to
150ºC | IPC-TM
-650
2.5.5.5 |
Volume
Resistivity | 1.7 x 10¹º | 1.2 x 10¹º | | MΩ·CM | COND A | IPC-TM
-650
2.5.17.1 |
Surface
Resistivity | 4.2 x 10^9 | 5.7 x 10^9 | | MΩ | COND A | IPC-TM
-650
2.5.17.1 |
Electrical
Strenghth | 31.8
(780) | 31.2
(780) | Z | KV/mm
(V/mil) | 0.51mm
(0.020") | IPC-TM
-650
2.5.6.2 |
Tensile
Modulus | 19650(2850)
19450(2821) | 16767 (2432)
14153 (2053) | X Y | Mpa(ksi) | RT | ASTM
D638 |
Tensile
Strength | 139(20.2)
100(14.5) | 203(29.5)
130(18.9) | X Y | Mpa(ksi) | RT | ASTM
D638 |
Flexural
Strength | 276
(40) | 255(37) | | Mpa(kpsi) | | IPC-TM
-650
2.4.4 |
Dimensional
Stability | <0.3 | <0.5 | X,Y | mm/m
(mils/inch) | after etch
E2/150ºC | IPC-TM
-650
2.4.39A |
Coefficient
of Thermal
Expansion | 11 14 46 | 10 12 32 | X Y Z | ppm/ºC | minus 55ºC
to 288ºC | IPC-TM
-650
2.4.41 |
| Tg | >280 | >280 | | ºC TMA | A | IPC-TM
-650
2.4.24 |
| Td | 425 | 390 | | ºC TGA | | ASTM
D3850 |
Thermal
Conducvitity | 0.71 | 0.69 | | W/m/ºk | 80ºC | ASTM
C518 |
Moisture
Absorption | 0.06 | 0.06 | | % | 48 hrs
immersion
0.060"
sample
Temperature
50ºC | ASTM
D570 |
| Density | 1.79 | 1.86 | | gm/cm³ | 23ºC | ASTM
D792 |
Copper
Peel
Strength | 1.05 (6.0) | 0.8 (5.0) | | N/mm (pli) | after solder
float 1 oz.
EDC Foil | IPC-TM
-650
2.4.8 |
| Flammability | N/A | V-0 | | | | UL 94 |
Lead-Free
Process
Compatible | Yes | Yes | | | | |
| Prod Model: |
BIC-637-V6.37 |
| Final Foil External: |
1.5 Oz |
| Final Height Of PCB: |
0.6mm |
| Surface Finish: |
Immersion Gold |
| Solder Mask Color: |
Green |
| Colour Of Component Legend: |
White |
| Minimum Trace And Space: |
6.5 Mil/8 Mil |
| Minimum / Maximum Holes: |
0.4/4.5mm |
| Via: |
Plated Through Hole(Pth) |
| Board Plating: |
0.0030" |
| Test: |
100% Electrical Test Prior Shipment |
| Type: |
Rigid Circuit Board |
| Flame Retardant Properties: |
V0 |
| Dielectric: |
RO4350b |
| Material: |
Hydrocarbon/Woven Glass |
| Insulation Materials: |
Glass Reinforced Hydrocarbon |
Founded in 2003, Bicheng Enterprise Limited is a professional PCB export enterprise. We have established a good relationship of cooperation with well-known enterprises in the same industry.
The factories have been ISO 9001-2008, ISO 14001-2004 and ISO/TS16949-2009 quality management system certified. Over the past 14 years, we have provided professional circuit board manufacturing solutions for more than 5000 companies worldwide.
Different plant scale to suit for your requirements
16000 square meter factory building
30000 square meter month capability
8000 types of PCB per month
ISO9001, ISO14001, TS16949, UL Certified
We have our own advantages to help you saving cost and time spent on PCB, booster your new products go to market quickly.
A) Various kinds of PCB products
Double sided PCB
Multilayer PCB up to 32 layers
FR-4 PCB (Tg130, Tg170)
High frequency PCB (RO4350B, RO4003C)
Aluminum PCB (1W/MK, 2W/MK, 3W/MK)
Flexible PCB
HDI PCB Board
B) Multiple PCB technology to meet the market demands
Blind via PCB, Via in pad PCB, Fine pitch BGA PCB
Impedance controlled PCB
Heavy copper PCB
Hybrid material PCB
C) Many discount policies for new customers
SMT stencil foil, free of charge
Prototype shipping cost, free of charge
Prototype test, free of charge
PCB panelization, free of charge
D) High quality PCB services
Engineering design prevents problems from occurring in pre-production.
Meet your PCB needs from prototype to mass volume production.
Eligible products rate of first production: >95%
Delivery on time: >98%, door to door shipment service
Customer complaint rate: <1%
Choose BichengPCB means you choose hassle free.
