Eoc User Terminal Device Eoc Slave
| Price: |
Negotiable/Piece |
| Trade Terms: |
FOB |
| Min Order: |
10/Piece |
| Pay Type: |
L/C,T/T,D/P |
| Prod Model: |
WEC-3702I E4 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Material: |
Plastic |
| Chip: |
Ar6400 |
Product Description
1. SummaryWEC3702I E4 equipment is the active EoC user terminal device that design and develop based on HomePlug AV standard. It is used to construct two-layer Ethernet transmission channel in
the CATV cable network.
CATV coaxial cable is used to transmit and receive Ethernet signals and does not affect the original CATV signals.Model DescriptionWEC3702I E4 AR6400 series chip
WEC701 E4 AR7400 series chip 2. Performance Characteristics Adopt high-speed multi-carrier modulation technique, PHY layer rate up to 200Mbps.
OFDM modulation, multi-carrier technology ensures stable data transmission
in the noise environment.
Adopt 128 bit DES data encryption, effectively protect the data transmission security.
Adopt standard interface, signal can transparently transmit to amplifier, tap etc equipmen t, and realize fast installation and debugging.
One cable two signal, plug and play, can connect any indoor CATV interface, provi de television and data signals at the same time.
Powerful data service function, fully meet the multi-service access requirements of the
radio and television operators.
Powerful and convenient NMS, support both remote and local configuration, administration an d maintenance.
Easy to open the service, terminal plug and play, boot to complete auto-synchronous
of the service configuration and server, and support safe and convenient service certifica tion function.
Support Sqlite database, safe and efficient storage of service data.
Prevail was founded in 2001, Hangzhou Prevail Optoelectronic Equipment Co., Ltd. Which is one of the earliest, largest, and most professional factory in CATV industry.
The factory is located in Industrial Development area, Guali town, Xiaoshan Hangzhou City, near Hangzhou Xiaoshan International Airport and Shanghai-Hangzhou-NingboExpressway. It is a scale and specialization company of CATV equipment research, development and production. Its production scale, products' quality and marketcoverageis in front of other companies in domestic market.
We have perfect modern enterprisemanagement system, also have a high-quality new product development, design, testing and detection teams, technical personnel who have junior degree is more than 20% of the total number of workers.
With the effort of many years in CATV equipment manufacturing industry, the technology, performance, research and developmentlevel is in the leading position of domestic market. We are good at studying RF technology and optical fiber transmission equipment, and set up the research and development center of digital TV, which make our products cover with wholeCATVsystem, analog and digital head-end equipment, 1550nm and 1310nm optical fiber transmission equipment, RF system transmission (bi-directional) equipment. This center offers a variety of optimization solutions and technical support for tri-networks integration; Offers technology planning and support for backbone remote transmission and large-scale IP backbone network. We are the professional manufacturer of CATV with domestic largest selection of CATV products currently.
Our company always adheres to the "excellence, quality first" principle of the quality, taking the leading in passing ISO9001 Quality Management System, actively implement the ISO 14001 Environmental Management System and OHSAS18001 Occupational Health and Safety Management Systems Certification.
We have million square meters of production workshop. Our company has industry-leading production assembly and debugging lines, SMT, high and low temperature oven room, the vibration test equipment, and other detection equipments, including HP, Rhodes and the gas, Anritsu and so on.
The aim of Prevail is doing good-quality products and taking the road of international brand. Our products cover with all cities and towns of domestic, even Europe, North America and other countries. To provide valuable, high-quality products and services to meet customer demand as our mission, with a new image and new fashion guide.
To build the best brand, and strive to become the domestic and world production and R &D base of Chinese CATV equipment.
