Mini OS2 MPO Fiber Optic Cable Single Mode Male to Male LSZH Plenum Round Cable

Name: Mini OS2 MPO Fiber Optic Cable Single Mode Male to Male LSZH Plenum Round Cable
Brand: all-electronics-online.com
SKU: 811648725
Availability: InStock
Rating: 4.3 (40 reviews)

Price:	US $ 31-32/Meter
Min Order:	1/Meter
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	PN-002
Color:	Yellow
Fiber Type:	Singlemode
Polishing:	PC
Fiber Count:	12F
Fanout Kit:	1
Application:	Sensor
Type:	Single-mode Fiber
Certification:	ISO9001
Connection Structure:	MPO-LC
Brand:	PUNO

Product Description

Mini OS2 MPO Fiber Optic Cable Single Mode Male to Male LSZH Plenum Round Cable

With its higher port density, MTP is easier to install - just pull 1 cable with 12 fibers for one easy plug-in. OFNP plenum-rated for in-wall use without conduit.

Application:

√ Multiple 100G channels;
√ CFP to CFP direct connect;
√ Distribution area connections;
√ 100G patch cord connection;
√ 100G extender cabling.

Feature:

√ High Density Fiber Management Solution;
√ 8 or 12 Fibers per connecter;
√ Mates to all MTP or MPO connectors;
√ Precision polished for minimum insertion loss and back reflection;
√ Push/Pull Connector Mating;
√ Plenum Rated Cable;
√ Fanouts to discrete simplex connecters available;
√ 50 and 62.5 micron core fiber available.

Cable Polarity - Type B Crossover(Full-Flipped):

MPO / MTP Connector:

MPO Multimode (OM3 and OM4) 24 fibre Connector
Connector Housing	Aqua
Ferrule	MT ELITE
Typical Insertion Loss	0.10 dB (average)
Maximum Insertion Loss	0.35 dB (Max)
MPO Singlemode (OS1/ OS2) 24 fibre Connector
Connector Housing	Yellow
Ferrule	MT ELITE APC
Typical Insertion Loss	0.10 dB (average)
Maximum Insertion Loss	0.35 dB (Max)
Return Loss	> 60 dB

Cable Technical Data:

Multimode OM3 (50/125)	Multimode OM4 (50/125)	Singlemode (9/125)
Optical Core	50μm +/- 2.5μm diameter	50μm +/- 2.5μm diameter	9μm +/- 0.4μm diameter
Optical Cladding	125μm +/- 1μm diameter	125μm +/- 1μm diameter	125μm +/- 0.7μm diameter
Primary Acrylate Coating	242μm +/- 5μm diameter	242μm +/- 5μm diameter	242μm +/- 10 to 15μm diameter (uncoloured / coloured)
Core Concentricity	1.5μm	1.5μm	0.5μm
Core Concentricity Error	<5%	<5%

Physical:

Cable	9 micron	62.5 micron
Minimum Bend Radius	30mm	30mm
Core/Cladding Diameters	9/125um	62.5/125um
Certification/Flame Rating	USA (UL)=OFNP, Canada (CSA)=OFN/FT6
Connectors	MPO / MTP
Ferrule Material	Glass Filled Resin
Guide Pins	Surgical Grade Stainless Steel
Polish	PC, 1 micron (typical) protrusion

Matched MTP / MPO Products:
